GB Bus Gran Viale

GB Bus Gran Viale is designed for high-capacity urban and BRT (Bus Rapid Transit) applications. Built for durability and passenger flow efficiency, it incorporates a diesel powertrain engineered for continuous city operation. The Gran Viale features disc brakes with ABS, EBD, and ASR and a stable air suspension system, ensuring safety and comfort even in dense traffic conditions. With a 12.5-meter length and modern design features, it supports demanding public transport operations with long service life and low operating costs.

Call

GVW (T)	19T
Seats	51
Diesel/Electric	Diesel
Capacity (cc)	7700
Max. Power (hp)	330
Max. Torque (N.m)	1200 @ 1200-1650 rpm
Max Speed (Km/h)	80
Gearbox	12 speed non-synchromesh ZF Transmission with an electronically regulated clutch
Brakes system	Front & rear Disc Brakes with ABS, EBD, ASR
Suspension	Air suspension
Avg. Fuel Consumption (km/L)/(km/kW)	3.5
Overall Length (mm)	12050
Overall Width(mm)	2550
Overall Height (mm)	3400
Wheelbase (mm)	6000
Ground Clearance (mm)	160
Luggage compartment	2
Fuel Tank Capacity	300
Tyres size	295/80 R22.5

GB Bus Gran Viale
